CARACTERÍSTICAS
- Hikvision
- Switch no Gestionable
- 8 puertos RJ45 10/100 Mbps PoE + 2Gb RJ45 Uplink
- 1 Puerto Hi-PoE hasta 90W
- 7 Puertos PoE hasta 30W
- Hasta 110W de potencia PoE Total
- PoE Extendido hasta 300m
- Consumo 65W
- IEEE 802.3af/at
ESPECIFICACIONES TÉCNICAS
| Carcasa |
Metal material, fan-free design |
| Peso Neto |
0.55 kg (1.21 lb) |
| Peso Bruto |
1.22 kg (2.69 lb) |
| Dimensiones (W X H X D) |
217.6 mm × 27.8 mm × 103.55 mm (8.6'' × 1.1'' × 4.1'') |
| Temperatura De Funcionamiento |
0 °C to 40 °C (32 °F to 104 °F) |
| Temperatura De Almacenamiento |
-40 °C to 85 °C (-40 °F to 185 °F) |
| Condiciones De Humedad |
5% to 95% (no condensation) |
| Humedad Relativa |
5% to 95% (no condensation) |
| Fuente De Alimentación |
48 VDC, 2.5 A |
| Max. El Consumo De Energía |
120 W |
| Consumo De Energía En Inactivo |
10 W |
| Modo De Instalación |
Wall-Mounted,Desk-Mounted |
| Surge Protection |
6 KV |
| Puertos |
8 × 10/100 Mbps PoE port,2 × Gigabit RJ45 port |
| Tabla De Direcciones MAC |
8 K |
| Capacidad De Conmutación |
5.60 Gbps |
| Tasa De Reenvío De Paquetes |
4.17 Mpps |
| Caché Interna |
4 Mbits |
| PoE Standard |
IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt |
| Pin De Alimentación PoE |
8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) |
| Max. Puerto De Alimentación |
Port 1: 90 W Ports 2 to 8: 30 W |
| Puerto PoE |
Hi-PoE: Port 1 PoE: Ports 2 to 8 |
| PoE Power Budget |
110 W |
| Largo Alcance |
Ports 1 to 8: up to 300 m. Long range performance may vary depend on camera model or cable condition. |
| VIP Port |
Ports 1 to 8: data on VIP ports is preferentially forwarded when bandwidth resources are insufficient. |
| EMC |
FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015) |
| Seguridad |
UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017) |
| Química |
CE-RoHS (2011/65/EU) |
- POE:
- SI
- Ethernet:
- 10/100
- Puertos:
- 8
- Enrackable:
- NO
- SFP:
- NO
- Level:
- Sin licencia
