| Cámara |
| Sensor de imagen |
1/1.8" Progressive Scan CMOS |
| Max. Resolución |
2560 × 1440 |
| Iluminación mínima |
Color: 0.0005 Lux @ (F1.2, AGC ON), B/W: 0 Lux with light |
| Tiempo de obturación |
1 s to 1/100,000 s |
| Lente |
Focal Length & FOV:
2.8 to 12 mm, horizontal FOV 107.4° to 39.8°, vertical FOV 56° to 22.4°, diagonal FOV 130.1° to 45.7°
8 to 32 mm, horizontal FOV 40.3° to 14.5°, vertical FOV 22.1° to 8.2°, diagonal FOV 46.9° to 16.5° |
| Lente |
Auto, Semi-auto, Manual |
| Iris Type |
Auto-iris |
| Apertura |
2.8 to 12 mm: F1.2, 8 to 32 mm: F1.6 |
| Montura del lente |
All In One Lens |
| DORI |
2.8 to 12 mm:
Wide: D: 60.0 m, O: 23.8 m, R: 12.0 m, I: 6.0 m
Tele: D: 149.0 m, O: 59.1 m, R: 29.8 m, I: 14.9 m
8 to 32 mm:
Wide: D: 150.3 m, O: 59.7 m, R: 30.1 m, I: 15.0 m
Tele: D: 400 m, O: 158.7 m, R: 80 m, I: 40 m |
| Iluminador |
Tipo de luz suplementaria: IR
Rango de luz suplementaria:
2.8 to 12 mm: Up to 30 m
8 to 32 mm: Up to 50 m
Luz de suplemento inteligente: Yes |
| Vídeo |
Main stream:
Performance mode:
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Proactive mode:
50 Hz: 12.5 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 15 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-stream:
Performance mode:
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Proactive mode:
50 Hz: 12.5 fps (640 × 480, 640 × 360)
60 Hz: 15 fps (640 × 480, 640 × 360)
Third Stream:
50 Hz: 1 fps (1280 × 720, 640 × 480)
60 Hz: 1 fps (1280 × 720, 640 × 480)
Compresión de video:
Main stream: H.264/H.265
Sub-stream: H.264/H.265/MJPEG
Third Stream: H.265/H.264
*Performance mode: main stream supports H.264+, H.265+
Vídeo bitrate: 32 Kbps to 8 Mbps
Tipo H.264: Baseline Profile, Main Profile, High Profile
Tipo H.265: Main Profile
Bit Rate Control: CBR/VBR
Codificación de video escalable (SVC): H.264 and H.265 encoding
Región de interés (ROI): 4 fixed regions for main stream |
| Audio |
Compresión de audio: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Velocidad de bits de audio: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Frecuencia de muestreo de audio: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Filtro de ruido ambiental: Yes |
| Red |
Vista en vivo simultánea: Up to 6 channels
API: Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP, OTAP
Protocolos: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
Usuario/operador: Up to 32 users
3 user levels: administrator, operator, and user
Seguridad: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, TLS 1.2, TLS 1.3
Almacenamiento en red: NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Cliente: Hik-Connect (proactive mode also supports), Hik-central Professional
Navegador web: Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+ |
| Mobile Communication |
SIM Card Type: MicroSIM
Frecuencia:
DS-2XS6A46G1-IZS/C36S80:
LTE-TDD: Band38/40/41
LTE-FDD: Band1/3/5/7/8/20/28
WCDMA: Band1/5/8
GSM: 850/900/1800 MHz
DS-2XS6A46G1-IZS/C36S80(US):
LTE-FDD: Band2/4/5/12/13/66/71
WCDMA: Band2/4/5
DS-2XS6A46G1-IZS/C36S80(LA):
LTE-TDD: Band38/40
LTE-FDD: Band1/2/3/4/5/7/8/12/17/28/66
WCDMA: Band1/2/3/4/5/8
GSM: 850/900/1800/1900 MHz
DS-2XS6A46G1-IZS/C36S80(JP):
LTE-TDD: Band41
LTE-FDD: Band1/3/8/11/18/19/21/26/28
WCDMA: Band1/6/8/19
Estándar:
DS-2XS6A46G1-IZS/C36S80: LTE-TDD/LTE-FDD/WCDMA/GSM
DS-2XS6A46G1-IZS/C36S80 (US): LTE-FDD/WCDMA
DS-2XS6A46G1-IZS/C36S80 (LA): LTE-TDD/LTE-FDD/WCDMA/GSM
DS-2XS6A46G1-IZS/C36S80 (JP): LTE-TDD/LTE-FDD/WCDMA |
| Imagen |
Wide Dynamic Range (WDR): 120 dB
Interruptor día/noche: Day, Night, Auto, Schedule
Mejora de la imagen: BLC, HLC, 3D DNR, Defog
Interruptor de parámetros de imagen: Yes
Configuración de imagen: Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
SNR: ≥ 52 dB
Máscara de privacidad: 4 programmable polygon privacy masks |
| Interfaz |
Audio:
1 input (line in), max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Alarma:
1 input, 1 output (max. 12 VDC, 1 A)
On-Board Storage:
Built-in memory card slot, support microSD card, up to 256 GB,
Built-in 256 GB eMMC storage (256 GB device model supports),
Built-in 512 GB SSD storage (512 GB device model supports),
Built-in 1 TB SSD storage (1 TB device model supports)
Reset Key: Yes
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
Salida de alimentación: 12 VDC, max. 1000 mA |
| Evento |
Evento Básico: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD error)
Evento inteligente: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, scene change detection, face detection
Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output, audible warning |
| General |
Alimentación: 12 VDC ± 20%, 4-pin M8 waterproof connector
1 TB/512 GB device model:
1. Standby power consumption: 45 mW
2. The average power consumption of 24 hours (4G transmission is excluded): 4.5 W
3. The max. power consumption: 20 W (6 W if without 12 V load)
Other device model:
1. Standby power consumption: 45 mW
2. The average power consumption of 24 hours (4G transmission is excluded): 3 W
3. The max. power consumption: 18 W (6 W if without 12 V load)
Material: Front cover: metal, body: metal, bracket: metal
Dimensión: 816.2 mm × 735.9 mm × 760 mm (32.1" × 28.9" × 29.9") (Max. size of the camera after it is completely assembled)
Dimensión del paquete: 862 mm × 352 mm × 762 mm (33.9" × 13.9" × 30.0")
Approx. 26.450 kg (58.3 lb.)
Con peso del paquete: Approx. 32.715 kg (72.1 lb.)
Condiciones de almacenaje: -20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing)
Condiciones de inicio y funcionamiento: -20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing)
Idioma: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Función general: Anti-banding, heartbeat, mirror, flash log, password reset via email, pixel counter |
| Batería |
Tipo de batería: Lithium
Capacidad: 360 Wh (90 Wh for each battery)
Voltaje de la batería: 10.8 V
Max. Output Voltage: 12.6 V
Temperatura de funcionamiento:
Charging: -20 °C to 45 °C (-4 °F to 113 °F)
Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
Vida de batería: More than 500 cycles
Ciclo de vida: Proactive mode: 8 days, Standby mode: 80 days
*in cloudy/rainy days (25 °C)
Battery Weight: Approx. 2.74 kg (6.0 lb.) (0.685 kg (1.5 lb.) for each battery) |
| Certificaciones |
EMC:
CE-EMC/UKCA (EN 55032:2015+A11:2020+A1:2020, EN 50130-4:2011+A1:2014);
RCM (AS/NZS CISPR 32: 2015);
IC (ICES-003: Issue 7)
RF:
CE-RED/UKCA (EN 301908-1, EN 301908-2, EN 301908-13, EN 301511, EN 301489-1, EN 301489-52, EN 62133);
ICASA: same as CE-RED;
IC ID (RSS-132 Issue 3, RSS-133 Issue 6, RSS-139 Issue 3, RSS-130 Issue 2, RSS-102 Issue 5);
MIC (Article 49-6-4 and 49-6-5 the relevant articles and MIC Notice No. 1299 of the Ordinance Regulating Radio Equipment)
Seguridad:
CB (IEC 62368-1:2014+A11)
CE-LVD/UKCA (EN 62368-1:2014/A11:2017)
LOA (IEC/EN 60950-1)
Ambiente:
CE-RoHS (2011/65/EU);
WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
Protección:
Camera: IP66 (IEC 60529-2013)
Resistencia al viento de 12 niveles, resistencia a una velocidad del viento de hasta 40 m/s |
