| Cámara |
| Sensor de imagen |
1/1.8" Progressive Scan CMOS |
| Max. Resolución |
2688 × 1520 |
| Iluminación mínima |
Color: 0.0005 Lux @ (F1.0, AGC ON), B/W: 0 Lux with white light |
| Tiempo de obturación |
1/3 s to 1/100,000 s |
| Ajuste de ángulo |
Solar Cover: Pan: 0° to 358°, tilt: -40° to 40°
Camera: Pan: 0° to 360°，tilt: -60° to 0° |
| Lente |
| Lente |
Fixed focal lens, 4 and 6 mm optional |
| Apertura |
F1.0 |
| Focal Length & FOV |
4 mm, horizontal FOV 95°, vertical FOV 51°, diagonal FOV 115°
6 mm, horizontal FOV 58°, vertical FOV 31°, diagonal FOV 69° |
| Montura del lente |
M16 |
| DORI |
| DORI |
4mm, D: 77 m, O: 30 m, R: 15 m, I: 8 m
6mm, D: 116 m, O: 46 m, R: 23 m, I: 12 m |
| Iluminador |
| Tipo de luz suplementaria |
White Light |
| Rango de luz suplementaria |
Performance mode: up to 30 m
Proactive mode: up to 10 m |
| Luz de suplemento inteligente |
Yes |
| Vídeo |
| Main stream |
50 Hz: 12.5 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 15 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-stream |
50 Hz: 12.5 fps (640 × 480, 640 × 360)
60 Hz: 15 fps (640 × 480, 640 × 360) |
| Compresión de video |
Main stream: H.265/ H.264
Sub-stream: H.265/H.264/MJPEG |
| H.264+ |
Performance mode: main stream supports |
| H.265+ |
Performance mode: main stream supports |
| Vídeo bitrate |
32 Kbps to 8 Mbps |
| Tipo H.264 |
Baseline Profile/Main Profile/High Profile |
| Tipo H.265 |
Main Profile |
| Bit Rate Control |
CBR/VBR |
| Región de interés (ROI) |
1 fixed region for main stream |
| Codificación de video escalable (SVC) |
H.265 and H.264 support |
| Audio |
| Frecuencia de muestreo de audio |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Filtro de ruido ambiental |
Yes |
| Compresión de audio |
G.711/G.722.1/G.726/MP2L2/PCM/AAC/MP3 |
| Velocidad de bits de audio |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) |
| Red |
| Seguridad |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Vista en vivo simultánea |
Up to 6 channels |
| API |
Open Network Video Interface, ISAPI, SDK, ISUP |
| Protocolos |
TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour, SSL/TLS, SNMP, HTTPS, 802.1X |
| Usuario/operador |
Up to 32 users. 3 user levels: administrator, operator and user |
| Almacenamiento en red |
Auto network replenishment (ANR) |
| Cliente |
iVMS-4200, Hik-Connect, Hik-Central
Proactive mode: Hik-Connect |
| Navegador web |
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+ |
| Mobile Communication |
| Frecuencia |
LTE-TDD: Band 38/40/41;
LTE-FDD: Band 1/3/5/7/8/20/28;
WCDMA: Band 1/5/8;
GSM: band 3/5/8 |
| Estándar |
LTE-TDD, LTE-FDD, WCDMA, GSM |
| Imagen |
| SNR |
≥ 52 dB |
| Wide Dynamic Range (WDR) |
120 dB |
| Interruptor día/noche |
Day, Night, Auto, Schedule |
| Mejora de la imagen |
BLC, HLC, 3D DNR |
| Configuración de imagen |
Rotate mode, saturation, brightness, contrast |
