| Especificación | Detalles |
|---|---|
| Antenna Connection | TwistPort™ - Quick Locking Waveguide Port |
| Antenna Type | Horn |
| Materials | UV Resistant ABS Plastic, Polycarbonate, HDPE, Aluminium, Stainless Steel |
| Environmental | IP55 |
| Pole Mounting Diameter | 40-80 mm (1.5-3.1 Inch) Recommended as close to 80 mm (3.1 Inch) as possible |
| Temperature | -35°C to +60°C (-31°F to +140°F) |
| Wind Survival | 160 km/h (100 mi/h) |
| Wind Load | 38/90 N - Front/Side at 160 km/h (100 mi/h) |
| Effective Projected Area | 311/741 cm² - Front/Side (48.2/114.9 in²) |
| Mechanical Adjustment | ± 20° Elevation, ± 20° Azimuth |
| Weight | 4.7 kg (10.3 lbs) – single unit* 6.1 kg (13.7 lbs) – single unit incl. package* |
| Single Unit | Retail Box: 540 x 365 x 160 mm (21.2 x 14.3 x 6.3 inch)* |
| Frequency Range | 5180 - 6000 MHz |
| Gain | 17 dBi |
| Azimuth Beam Width -3 dB | H 45° / V 42° |
| Elevation Beam Width -3 dB | H 17° / V 16° |
| Azimuth Beam Width -6 dB | H 60° / V 60° |
| Elevation Beam Width -6 dB | H 25° / V 25° |
| Beam Efficiency | 95% |
| Front-to-Back Ratio | 27 dB |
Dimensiones 457x334x101mm
Garantía hasta 3* años
